CNC Turning

CNC Turning Capabilities



CNC Turning Services

- Capacities from 10 - 650mm diameter

- Part lengths up to 1500mm can be machined in one setting

- Volume batch manufacturing with scheduled call-off available

- Specialists in stainless steel components, with extensive
expertise in mild steel, non-ferrous and plastics materials

- Let us help with "design for production" for cost control

- We can turn parts from solid, tubing or castings as required


HAAS TL-15 CNC SUB SPINDLE LATHE

- We are now one of the largest users of the HAAS TL-15 CNC sub spindle lathe machines in Europe

- 368 x 864mm Max Capacity

- 12 Position VDI/BOT Turret

- 30HP Vector Drive Spindle, 50-5000 RPM

- 50.8mm Bar Capacity

- Anti-flex, Cast Iron, Torque Tube Bed

- 8HP Sub-Spindle, 0-4000 RPM

- HAAS Automation's TL-15 turning centre is a dual-spindle CNC lathe built on the very popular HAAS SL-20 foundation. Double-end part capability, a max capacity of 368 x 864mm and a bar capacity of 50mm (main spindle) make this twin-spindle turning centre a high-production machine. The TL-15 also boasts a hybrid tool turret (6 VDI 40 and 6 bolt-on tools) and the ability to add options like live tooling and full C-axis capabilities to the main spindle.
